SUP COMPOSITE TECHNOLOGY

CST: CUSTOM SURF TECHNOLOGY

1 Light finish and weight saving graphics
2 Glass fibre layer
3 Solid glass force patch
4 Extra strong bamboo reinforcement
5 Vector Net rail frame
6 Solid glass force patch
7 Ultra light fibre layer
8 Light and strong EPS core

Our Custom Surf Technology combines a lightweight custom layup with features such as Carbon stripes, Vector net and bamboo reinforcements providing the right amount of strength and flex needed for the high performance ProWaves and our Sky Surf foil boards.

VEC: VACUUM EPOXY CONSTRUCTION

1 Light finish and weight saving graphics
2 Glass fibre heel patch
3 Bamboo heel patch
4 Glass reinforcement rail band
5 Full carbon layer
6 Full high densitiy PVC layer
7 Carbon fibre heel patch
8 Light fibre layer
9 Light EPS core
10 Light fibre layer
11 Full high densitiy PVC layer
12 Solid glass layer

 VEC – VACUUM EPOXY CONSTRUCTION

Our Vacuum Epoxy Construction comes in a complex multi-step vacuum process with reinforcement patches in key areas such as boxes, centre spine and a full bamboo patch in the entire stance area. The light yet strong construction comes with a hand sanded finish adding to the unique custom appeal of this technology. A strong construction with significantly lower weight.

VCT: VECTOR NET TECHNOLOGY

1 Light finish and weight saving graphics
2 Ultra light fibre layer
3 Glass core stringer
4 Vector net rail frame
5 Extra strong Bamboo reinforcement (stance area)
6 Solid glass layer
7 Ultra light fibre layer
8 Super light EPS core

Our new Vector Net Technology – with it’s stringer and bamboo wood reinforcements in key areas – ensures a great strength to weight ratio and comes with exceptional frame stability for a direct and responsive feel.

BS: BAMBOO SANDWICH TECHNOLOGY

1 Light finish and weight saving graphics
2 Ultra light fibre layer
3 Glass reinforcement rail band
4 Glass core stringer
5 Caramel Bamboo Sandwich (front half)
6 Biax fibre layer
7 Solid glass layer
8 Super light EPS core

A lightweight bamboo wood / glass composite construction with great strength and unique optics. Combined with some extra glass reinforcements, it absorbs high impact forces. Overall a very durable layup with unique wooden deck optics and great weight / price ratio.

CFWC: CORK / FLAX / WOOD COMPOSITE LIGHT FINISH TECHNOLOGY

1 Light Finish and weight saving graphics
2 Ultra light fibre layer
3 Glass reinforcement rail band
4 Uni-Directional natural Flax Fibre layer
5 Glass reinforcement patch
6 Extra strong wood patch from sustainable forestry
7 Light glass layer
8 Natural Cork Sandwich
9 Ultra light fibre layer
10 Super light EPS core

Built with Flax, Cork, Wood and Bio Resin instead of the classic Glass and PVC sandwich, our Eco technology uses sustainable plant based raw materials wherever possible, without compromising performance.

• Natural Flax fibre composite offers a very good strength / weight / flex ratio and replaces the classic oil based Glass / Carbon composite layup

• Cork sandwich is not only a natural source, but it also brings superior shock absorption properties and replaces the oil based PVC sandwich

• Sicomin’s GreenPoxy® Bio Resin contains a higher degree of plant based elements than traditional resin. Bio Resin is used in all models throughout the Fanatic range

• Wood veneer from sustainable forestry is used across the entire base of the board for superior optics and a unique flex response

BXF: BIAX FIBRE LIGHT FINISH TECHNOLOGY

1 Light finish and weight saving graphics
2 90° fibre layer
3 Reinforcement rail band
4 Extra strong wood veneer (stance / step area)
5 45° Biax fibre layer
6 90° fibre layer*
7 Ultralight fibre layer
8 Super light EPS core

When combined with the sandwich construction, this high quality Full Biax Glass specification provides an optimised weight / stiffness / flex ratio.

*you might find higher grade components in your BFX board - such as PVC, Carbon etc., as we have slight variations in our different BXF models.

PL: PURE LIGHT TECHNOLOGY

1 Single Skin top coat
2 Glass reinforcement rail band
3 Glass fibre layer
4 Glass reinforcement layer
5 Extra strong wood patch (stance area)
6 Extra solid glass layer
7 Glass fibre layer
8 Super light EPS core

The Pure Light technology is an exceptionally durable construction with a great weight / strength ratio. Created for frequent use, the glass reinforcements ensure optimum stiffness. A thick, durable outer skin gives the board’s hull great strength, as well as extra ding and impact resistance.
